Plastic Bag Making Machine Price

Basic Info

Speed	High
Continuous-Rolled	No
Sealing & Cutting	Heat Sealing and Cutting
Layer	Single
Machine Type	Bag Forming Machine
Computerized	Computerized
Type	Side Sealing Bag Making Machine
Material	BOPP/OPP/PE/PP etc
in Stock	Yes
Hole Puching	8mm
Photocell	Yes
Transport Package	Wooden Plate
Trademark	RUIJI
Origin	Ruian, Zhejiang
HS Code	8441200000
Production Capacity	360 Per Year

Product Description

RQL Series Heat Sealing and Cutting Machine(Side sealing machine)Use: This machine is suitable for the making garment bag, sock bag, towel bag, bread bag, underwear bag, stationery bag and so on. Processed The Material:BOPP, PP, PE,PVC, etc. The Function and Characteristic:1. Microcomputer control machine, stepping motor (or servo motor) control film feeding,2. Computer control length, Accurate and stable photocell tracking, Stop automatically when losing the tracking. 3. Auto counting and auto giving an alarm. Also could set auto stop working.3. The automatic computation and to assigns quantity warning. 4. Lace heat-sealing; automatic punching; automatic gluing.5.Cylinder material hatch. Bottom gusset. Pillow facility.6. Optional facility: 1).Cylinder material hatch. 2).Bottom gusset. 3).Pillow facility.4). EPC 5).Ultrasonic facility, etc. (Adding by your requirement)
Main Technical Parameters:

Model		RQL-400	RQL-500		RQL-600		RQL-700		RQL-800	RQL-900
Length of finished product		30-380	30-480		60-580		70-680		80-780	90-880
Width of finished product		25-500	45-600		50-600		50-600		55-600	60-600
Speed of Bag-making		30-240
Accuracy of finished product		±0.3
Total power		3.5	3.5	4		4.5		5			6
Weight		600	700	800		900		1000			1100
Dimension (mm)	Length	3500	3500	3500		3500		4000			4000
	Width	900	1000	1100		1200		1300			1400
	Height	1300	1300	1300		1300		1300			1300

Model		RQL-1000	RQL-1100	RQL-1200	RQL-1300	RQL-1400	RQL-1500
Length of finished product(mm)		90-980	90-1080	90-1180	90-1280	90-1380	90-1480
Width of finished product(mm)		80-700
Speed of Bag-making (pcs/min) 1		30-180
Accuracy of finished product(mm)		±0.3
Total power(kw)		7.5	8.0	8.5	9.0	9.5	10
Weight(kg)		1200	1250	1300	1350	1400	1450
Overall dimension(mm)	Length	4000
	Width	1500	1600	1700	1800	1900	2000
	Height	1760

REMARKS: The Min. width of bag are according your dimension, but Pls note in the contract. More information about our Machine, pls contact us.

Web:http://rjmachinery.en.made-in-china.com

Packaging & Delivery
1.Packaging Details: wooden pallet or plastic film(If need , Fumigation wooden case as option

2.Delivery Detail: 15-25 days after receiving order deposit

3.Port: Ningbo port

RFQ
1.Where is your factory Located
Our Factory Located in Ruian City ,Zhejiang Province ,China .It is about 40minutes by plane from Shanghai, about 5 hours by train fromShanghai .We are pleasured to pick up you when you arrived .

2. What should we charge for your engineer?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary.

3. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.

4. How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 80USD/day.

5. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.

THANKS FOR YOUR READING.
